Εφαρμογή
Ξύλο, οργανικό γυαλί, πλαστικό, ενδύματα, χαρτί, δέρμα, καουτσούκ και άλλα μη μεταλλικά υλικά.
Τεχνικά Χαρακτηριστικά
| Laser - Type | Sealed CO2 laser tube |
| Laser Power | 80w |
| Cutting Area | 1300*900mm |
| Whole Machine Size | 2115*2600*1880mm |
| Cutting Speed | 0 - 24,000mm/min |
| Resetting Positioning Accuracy | ±0.02mm |
| Working Voltage | AC 110-220V±10%, 50-60Hz |
| Gross Power | <1,500W |
| Operating Temperature | 0-45℃ |
| Operating Humidity | 5-95% |
| Minimum Shaping Character | English 1x1mm |
| Work Table | 18cm lift platform |
| Driving System | Stepper |
| Cooling Mode | Water-cooling and protection system |
| Auxiliary Equipments | Exhaust-fans, air-exhaust pipe |
| Controlling Software | DSP control system |
| Compatible Software | CorelDraw AutoCAD Photoshop |
